About us
Since 1968 the name Baublies has been synonymous with customized roller burnishing solutions. Our Team of experienced specialists is completely devoted to the innovative fine machining process and continually improves it. This has enabled the team members to obtain know-how unique in this field worldwide. As a trendsetter and a progressive source of roller burnishing technology, Baublies develops or optimizes customized roller burnishing, diamond burnishing and forming tools. This focus on innovation is an important basis for adapting to the changing requirements and needs of the market quickly and at short notice. Baublies tools cover virtually all fine machining tasks for smoothing and compressing external and internal contours.
Address
Raitestraße 25
71272 Renningen
Germany
E-mail: baublies@baublies-group.com
Phone: +49 7159 928790
Internet: www.baublies.com
Unit C, 11/F, Honor Crest, 6029 Shennan Blvd.
518040 Shenzhen, Guangdong
China
E-mail: baublies@euro-me.com
Phone: +86 755 8384 2073
Internet: www.euro-me.com
Contact person:
Hao Hu
Brand Marketing Manager
E-mail: baublies@euro-me.com
Phone: +86 137 60108545
Products & Services
There are many possibilities to improve the quality of your products. Baublies roller burnishing technology is one of the most economical ones. Roller burnishing is the economical, easy- to- use and reliable creation of maximum surface quality. During this process the fatigue strength and the hardness of the workpiece is increased. During this non cutting process metal workpieces are smoothened and strain-hardened by rolling elements.
The Advantages:
- surfaces of low roughness
- decreased risk of crack formation caused by micro grooves
- greater surface resistance to wearing and corrosion due to higher material ratio-shifting of the material fatigue limits due to internal compressive stress and strain hardening.
COLIBRI - Perfect finish for sophisticated workpieces
Small, fine and in excellent Baublies quality: these are the burnishing tools which we have developed for filigree applications. We have optimized our many years of know-how in diamond burnishing for the machining of small precision parts and thin-walled workpieces in a compact form. Diamond burnishing tools from the COLIBRI series are always optimally suitable when the peak-to-valley height of filigree workpieces is to be minimized and at the same time the strength is to be increased.
Single-Roller burnishing tool variable
Burnishing in convincing quality:
Extremely smooth surfaces in just seconds. Surface roughness of under Rz 1µm, short cycle times and low investments with fast amortization make chipless roller burnishing a high-quality, cost effective alternative to any cutting process. Variable single-roller burnishing tools are flexibly adjustable for various contours and can be used in hard-to-reach places. The rolling unit can be swiveled by 180°.
ADVANTAGES:
• adjustable angle for various contours
• suitable for work hardening tasks
• universally useable
Multi-roller burnishing tools
Multi-roller tools are offered in a broad range of standard and special designs. They are used to work cylindrical holes, shafts, tapers and plane surfaces. The advantages of multiple rollers working simultaneously is a fast and economical machining without cross force to the rotation axis. These type of tools are used on all established types of machines.
Depending on the roller burnishing task, several hardened rollers are arranged in the cage. A taper supports the rollers and provides the contact force for forming the material. The rolling diameter is adjusted by axial shifting of the taper relative to the roller. The simultaneous engagement of several rollers results in a short processing time.
Baublies forming tool for beading
Forming in convincing quality: Forming tools from Baublies are used in a wide variety of applications including expanding, flanging and beading. Baublies forming tools are versatile, robust and durable. They enable the machining of small series on standard machines as well as the machining of large series on specialized machines.
ADVANTAGES:
• high process reliability
• quick processing and short cycle times
• high quality
Diamond burnishing tools
Diamond-burnishing tools expand the range of applications of roller burnishing technology, as even hardened materials up to approximately 60 HRC can be roller burnished. In the process, a high-precision, micropolished diamond glides over the surface. As soon as the yield point of the material is exceeded, the profile peaks of the workpiece surface flow into the adjacent recesses in the µm range. Compared to the machining by means of rollers, the contact area between the workpiece and the diamond is much smaller. Therefore, plastic cold working with a reduced influence of force can take place. Baublies diamond roller burnishing tools advance into hardness and diameter areas in which conventional roller burnishing tools cannot be used due to the workpiece characteristics or geometry.
